12V DC Lightweight Bodyworn COFDM Video Transmitter AHD Wireless Audio Video Sender 200mW High Resolution 1080p 60fps

Place of Origin : China

Brand Name : Kimpok Technology

Model Number : KP-AHD200MW

Packaging Details : International standard packing

Price : Negotiation

Certification : CE

MOQ : 1 Piece

Payment Terms : T/T, PayPal, Alipay

Supply Ability : 5000/month

Delivery Time : 1-3 working days

Product name : AHD HD wireless video transmitter

Modulation : COFDM 2K

Power : 12V DC

Video encoding : H.265/H.264

Resolution : 1080p@60fps

RF power : 200mW

Contact Now

COFDM Video Transmitter Introduction:

KP-AHD200MW 1080P HD transmitter is a powerful HD transmit system,using the core of mobile communication technology COFDM(multi-carrier modulation technique),which can transmit good quality and stable full-HD digital video signal under the condition of high speed mobile and heavy building blocks transmission in city environment. Support full HD 1080P H.265 encoding format and HD input as well support stereo balance audio input and narrowband transmission system.

Robot Transmitter Features:

  1. COFDM modulation;
  2. Low delay, lightweight, live broadcast;
  3. Support Full-HD quality image;
  4. Support 1080i/1080P HD transission;
  5. Built-in with HDM-I or HD-SDI interface(single selection);
  6. Support composite standard video and balanced audio input;
  7. All parameters can be adjusted by user;

Specification:

Voltage

DC5V~DC14V
Current

≤0.6A DC12V

Video input

 CVBS: support HD1080P,720P,576,480; 30FPS
Control input RS232; 19200
Frequency 300mHz-900mHz (optional)
Bandwidth 2/2.5/4/8MHz(adjustable)
Output power 200mW
Data encryption AES 128bit (user-defined password)
Modulation COFDM
Modulated mapping

QPSK(4QAM); 16QAM; 64QAM
Bandwidth

2/4/6/8M (adjustable)
FEC 1/2, 2/3, 3/4, 7/8
Guard Interval 1/32, 1/16, 1/8, 1/4
Video Compression H.265/H.264/MPEG-4
Standard Video Format PAL/NTSC (auto adaptation)
Parameter control method Set the related parameters through the control panel
RF Interface SMA
Working temperature -20℃~75℃
Transmission distance 1-40km max LOS (on air); 1-2km on ground station
Dimension 132*90*26mm
Weight 420g
