20km Drone VTX Digital HD UAV Video Transmitter AES Encryption HD-MI Input

Introduction of HD Drone Video Transmitter:

KP-HDT1W COFDM transmitter is a new designed wireless mobile video transmission system with great features and stable performance. The highly integrated transmission system provided superior performance in LOS (line-of-sight) and NLOS (non line-of-sight) condition.

KP-HDT1W video transmitter is designed for secure, high quality video transmission in multipath environments such as metropolitan areas. It's a high efficiency transmitter design with up to 1000mW RF output power and features such as full frequency band channelization, MPEG4/H.264 compression, narrow-band and video data encryption.

KP-HDT1W transmitter is designed to withstand harsh environments and are ideal for law enforcement, surveillance, UAV, UGV, and other applications requiring high quality video transmission in a compact, rugged package.

1W UAV video TX Parameters:

Features of UAV video link:

1. AES encrypted video transmission
2. Aluminum alloy casing with good shock resistance
3. External digital frequency controller for users easy adjust on the spot
4. Mobile video transmission in NLOS(NO LINE OF SIGHT) condition and environment
5. Work frequency adjustable in appointed frequency range
6. COFDM modulation and H.264 compression for stable and high quality audio and video signal
7. Support HDMI signal input, video and audio signal input simultaneous
8. Multiple bandwidth adjustable 2/4/6/8 MHz
9. Video input PAL/NTSC optional
10. Parameters adjustable: there is a frequency modulator to connect with TX and RX to change the bandwidth, frequency and so on.

Receiver parameter:
